【 Product Recommendation 】 Inductive Sensor Ultra Small Series

Ultra small integrated circuit proximity switches and proximity sensors can be installed in small and compact spaces, with simple installation, high working accuracy, fast response frequency, and good anti-interference performance. They are the first choice for high-precision equipment and small object detection.

Inductive sensor ultra small series

D3, M4, D4, M5, Q5 have complete rules

Accurate detection/stable performance/compact size/strong anti-interference ability/long lifespan

Product advantages：

1. Accurate detection and fast response

Capable of sensing objects within 0.6mm, with a response time of 0.1ms and a switching frequency of 2-3KHZ.
2. Stable performance and strong anti-interference ability

(1) High temperature resistance of 70 ° C and low temperature of -25 ° C: suitable for both outdoor and indoor equipment, with low temperature drift and high detection accuracy.

(2) Protection level IP67: Waterproof and dustproof.

(3) High quality pure copper wire: The wire adopts pure copper wire core, with good conductivity, matte wear-resistant wire skin, bending resistance, waterproof and oil resistant, excellent quality, and suitable for various environments.

3.Multiple protection, security and stability

Not only does it protect the product itself, but it also protects the equipment from damage.

（1）. Short circuit protection: When the load is short circuited, it not only protects itself but also prevents the load from being burned out.

（2）. Overload protection: It automatically protects when there is a problem with the load causing an increase in current.

(3) Reverse polarity protection: The positive and negative poles of the product's power cord are reversed, which will not burn out the product.

(4) 4.10-30V wide voltage: voltages within DC10-30V can be used normally for a long time.

4.Multiple sensing distances

D3: Leveling detection distance: 0.6mm/0.8mm/1.0mm

M4: Leveling detection distance: 0.6mm/0.8mm/1.0mm

D4: Leveling detection distance: 0.8mm/1.0mm/1.5mm

M5: Leveling detection distance: 0.8mm/1.0mm/1.5mm

Q5: The flush detection distance is 0.8mm/1.0mm/1.5mm

5.Product mechanical diagram

6.Application industry
