NPN Normally Closed Output Inductive Sensors With 3mm Detection Distance

10 pieces
MOQ
Negotiable
Price
NPN Normally Closed Output Inductive Sensors With 3mm Detection Distance
Features Gallery Product Description Chat Now
Features
Specifications
Features: Position Detection
Mounting Type: Quasi-flush
Type: Inductive Proximity Sensor
Theory: Inductive Proximity Sensor
Output: 10-30VDC
Installation Type: Quasi-flush
Protection Grade: IP67
Ambient Temperature: -25℃ To +70℃
Highlight:

NPN Normally Closed Output Inductive Sensors

,

3mm Detection Distance Inductive Sensors

,

NPN Inductive Proximity Sensor
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: IS2-M8NC30-S0C2/B
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Product Description
NPN Normally Closed Output Inductive Sensors With 3mm Detection Distance
Product Overview

Industrial-grade inductive proximity sensor featuring NPN normally closed output with 3mm detection distance, designed for reliable position detection in demanding environments.

Key Specifications
Attribute Value
Features Position detection
Mounting Type Quasi-flush
Type Inductive Proximity Sensor
Output 10-30VDC
Installation type Quasi-flush
Protection grade IP67
Ambient temperature -25℃ to +70℃
Product Features
  • Installation type: Quasi-flush
  • Sensing range Sn: 3mm
  • Output function: NPN Normally Closed
  • Supply voltage: 10-30VDC
  • Connection method: 2 meter cable
  • Housing material: Stainless steel
Technical Specifications
Installation type Quasi-flush
Sensing range Sn 3mm
LED display Yes
Connection method 2 meter cable
Shell Stainless steel
Working voltage 10-30VDC
Allowable ripple voltage <10%
No load current <10mA
Max. load current 200mA
Current drop <0.01mA
Voltage drop <1.5V
Switching frequency 1kHz
Response time 0.2ms
Switched reluctance <15%sr
Repeat accuracy <1.0%sr
Protection grade IP67
Ambient temperature -25℃ to +70℃
Temperature drift <10%sr
Short-circuit protection/Reverse polarity protection Yes
Overload current protection 220mA
Sensing surface material PBT
Product Diagrams
NPN Normally Closed Output Inductive Sensors With 3mm Detection Distance 0
Dimension Diagram
NPN Normally Closed Output Inductive Sensors With 3mm Detection Distance 1
Connection Diagram
