Home /Products/RJ45 Connectors/RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ

RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ

80
MOQ
Negotiable
Price
RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ
Features Gallery Product Description Chat Now
Features
Specifications
Pin: 4
Material Of Grip Body: TPU,black
Contact Nut Material: Brass,nickel-plated
Seal Material: FPM/FKM
Ambient Temperature: -25~+85℃
Insulation Resistance: ≥100MΩ
Voltage: 48V
Rated Current: 1.5A
Highlight:

IP20 RJ45 Connector

,

1.5A RJ45 Connector

,

Durability RJ45 Connector
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: RJ45S-10/E10K
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Product Description
RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ
Product Attributes
Attribute Value
Pin 4
Material of grip body TPU, black
Contact nut material Brass, nickel-plated
Seal material FPM/FKM
Ambient temperature -25~+85℃
Insulation resistance ≥100MΩ
Voltage 48V
Rated current 1.5A
Product Description

The RJ45 Connector is manufactured with high-quality materials to ensure durability and longevity. The contact carrier material is PA (black), providing excellent resistance to wear and tear along with corrosion protection. This material also offers high heat resistance, ensuring reliable performance at elevated temperatures.

RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ 0
Technical Specifications
Specification Value
Thread type RJ45
Contact nut material Brass, nickel-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material TPU, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP20
Pin Configuration
Pin assignment Wire color PIN Rated current Voltage Wire gauge Cable outlet Length Model No.
RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ 1 1 = YE
2 = OR
3 = WH
6 = BU		 4PIN 1.5A 48V 2×2×0.25, shielded (2×2×24AWG) Straight 10M RJ45S-10/E10K
Applications

The RJ45 connector is suitable for various networking applications including:

  • Network switches, routers, and modems
  • Ethernet cable production
  • Commercial and residential networking
  • Office and data center installations
RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ 2 RJ45 Connector with Durability IP20 Class Contact Resistance ≤5mΩ 3
Support and Services
  • Product installation guidance and troubleshooting
  • Technical consultation for product selection and compatibility
  • Customization services to meet specific requirements
  • Performance optimization and testing services
  • Warranty and repair services for defective products
Frequently Asked Questions
Where is this product manufactured?

This product is manufactured in Guangdong, China.

Does this product have any certifications?

Yes, this product is CE certified.

What is the minimum order quantity for this product?

The minimum order quantity is 80 pieces.

Is the price of this product negotiable?

Yes, we offer different pricing based on order quantity.

How is this product packaged?

The product is packaged in polybags within export cartons.

What is the delivery time for this product?

Delivery time is 5-8 working days for MOQ (80 pieces). For larger quantities, please contact the seller.

What payment terms are accepted?

We accept T/T, Western Union, and MoneyGram.

What is the supply capacity?

Production capacity is 100,000 pieces per month.
