Home /Products/RJ45 Connectors/RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3

RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3

80
MOQ
Negotiable
Price
RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3
Features Gallery Product Description Request A Quote
Features
Specifications
Material Of Grip Body: TPU,black
Ambient Temperature: -25~+85℃
Pollution Degree: 3
Rated Current: 1.5A
Contact Resistance: ≤5mΩ
Insulation Resistance: ≥100MΩ
Mating Cycles: >100
Cable Outlet: Straight
Highlight:

3 Pollution Degree RJ45 Connector

,

Insulation Resistance RJ45 Connector

,

48V RJ45 Connector
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: RJ45S-3/E60K
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Product Description
RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3
Product Attributes
Attribute Value
Material of grip body TPU, black
Ambient temperature -25~+85℃
Pollution degree 3
Rated current 1.5A
Contact resistance ≤5mΩ
Insulation resistance ≥100MΩ
Mating cycles >100
Cable outlet Straight
Product Description

Rated for a current of 1.5A, the RJ45 Connector can handle power-intensive applications with ease. It supports wire gauges of 26AWG, making it a versatile choice for a variety of Ethernet RJ45 Connector applications.

With a voltage rating of 48V, this connector is designed to meet the needs of modern Ethernet networks. Whether you're connecting two devices or a whole network, the RJ45 Connector is up to the task.

Overall, the RJ45 Connector is a reliable and durable choice for Ethernet RJ45 Connector applications. With a customized length, FPM/FKM seal material, and support for a wide range of wire gauges and voltage levels, it's a versatile choice for any application.

RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3 0
Technical Data
Specification Details
Thread type RJ45
Contact nut material Brass, nickle-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material TPU, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP20
Pin Assignment
Pin Wire Color Rated Current Voltage Wire Gauge Cable Outlet Length Model No.
1 = WH/OR
2 = OR
3 = WH/GN
4 = BU
5 = WH/BU
6 = GN
7 = WH/BN
8 = BN		 8 1.5A 48V 4×2×0.16, shielded (4×2×26AWG) Blueish green, PVC, OD=6.6 Straight 3M RJ45S-3/E60K
RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3 1 RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3 2 RJ45 Connector With ≥100MΩ Insulation Resistance 48V Pollution Degree 3 3
Support and Services
  • Assistance with product installation and setup
  • Troubleshooting and diagnosis of issues
  • Repair and replacement services for defective products
  • Product training and education for customers
  • Technical documentation and resources for the product
  • Ongoing customer support and communication
FAQ
Q: Where is this product manufactured?

A: This product is manufactured in Guangdong, China.

Q: Does this product have any certifications?

A: Yes, this product is CE certified.

Q: What is the minimum order quantity for this product?

A: The minimum order quantity for this product is 80.

Q: Is the price of this product negotiable?

A: Yes, we will offer different price according the quantity.

Q: How is this product packaged?

A: This product is packaged in polybag packing, export carton.

Q: What is the delivery time for this product?

A: The delivery time for this product is 5-8 working days for MOQ 80pcs, if more quantity, please contact with seller.

Q: What payment terms are accepted for this product?

A: The payment terms accepted for this product are T/T, Western Union, and MoneyGram.

Q: What is the supply ability of this product?

A: The supply ability of this product is 100000 pieces per month.
