Home /Products/RFID System/RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5

10 pieces
MOQ
Negotiable
Price
RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5
Features Gallery Product Description Request A Quote
Features
Specifications
Features: High Reading And Writing Speed
Series: M30 Series
Description: RFID HF Read/write Head
Operating Temperature: -30℃~+70℃
Voltage Rating: 18-30V
Interface: M12 4 Pin Male Connector
LED Display: 1 X LED, Blue
Housing Color: Matte Silver(metal)+Nylon(plastic)
Highlight:

IP67 RFID Reader Head

,

M30X1.5 RFID Reader Head

,

RS-232 LED Display RFID Reader Head
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: KRH-M30G-R2
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Paper box packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000 pieces per month
Product Description
RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5
Product Specifications
Series M30 Series
Features High reading and writing speed
Description RFID HF Read/write Head
Operating Temperature -30℃~+70℃
Voltage Rating 18-30V
Interface M12 4 Pin Male Connector
LED display 1 x LED, blue
Housing color Matte silver(metal)+Nylon(plastic)
Product Features
  • High protection level (IP67) and strong corrosion resistance for harsh industrial environments
  • High reading and writing speed to improve production efficiency
  • Supports multiple communication protocols including RS232, RS485, Modbus RTU
  • High stability and reliability for 24/7 operation
RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 0
Key Characteristics
Design
  • LED status display
  • Power supply and communication interface
Area of application Identification tasks on small assembly lines in harsh industrial environments. Mainly used in 3C, new energy and other industries
Electrical Interface

KRH-M30G with RS-232 interface, using a 4Pin-M12-ACODED-Male connector:

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 1
Pin Assignment Description
1 +24V Power supply positive
2 TX RS-232 TX
3 0V Power supply negative
4 RX RS-232 TX
LED Operating Display
Name Color State Description
SYS Blue Off The reader is power off.
On The reader is powered on and working properly.
20Hz flashing Tags was detected in the main identification area (RSSI signal is the strongest).
8Hz flashing Tags was detected in the secondary identification area (RSSI signal is medium).
4Hz flashing Tags was detected in the critical identification area (RSSI signal is weak).
Installation Guidelines
Reliable Identification Area

The tag should be in the center area of the sensing range:

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 2
Metal-free Area

The KRH-M30G can be flush-mounted in metal. Allow for a possible reduction in the field data. To avoid any influence on the field data, the distance "R" should be kept to ≥40mm.

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 3

In order to avoid potential conducted interference, it is recommended to use nonmetallic brackets to cut off the transmission path of conducted interference.

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 4
Minimum Distance Between Readers

KRH-M30G side by side: to avoid any influence between the readers, the distance "D" should be kept to ≥80mm.

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 5

KRH-M30G face-of-face: to avoid any influence between the readers, the distance "D" should be kept to ≥150mm.

RFID Reader Head 0-70mm Read Write Range With RS-232 LED Display IP67 M30X1.5 6
Technical Specifications
Model No. KRH-M30G-R2
Radio frequencies
Operating frequency 13.56MHz
Antenna Integrated
Read /Write range 0~70mm(Related to the tags)
ISO standard ISO 15693
Electrical Data
Supply voltage 9~30VDC
Current consumption ＜60mA@24V
Communication interface RS-232
Transmission speed 9600~115200 bps
Transmission distance ＜10m
Connector 4Pin-M12-ACODED-Male
Permitted ambient conditions
Operation temperature -30℃~+70℃
Storage temperature -40℃~+85℃
Degree of protection IP67,according to EN 60529
Shock resistance 7M2,500 m/s2,according to EN 60721-3-7
Vibration resistance 7M2,200 m/s2,according to EN 60721-3-7
Torsion and bending load Not permitted
Mechanical specifications
Housing Material Brass nickel plated (metal) + Nylon (plastic)
Housing color Matte silver (metal) + Black (plastic)
Weight About 70g
Dimensions M30 x 1.5/L=65mm
Housing shape Tubular
Thread code M18 x 1.5
LED display 1 x LED, blue
Standards, specifications, approvals
Proof of suitability CE FCC RoHS WEEE
