Max. 120mV Ripple Industrial Power Supply 47-63Hz Input Frequency
  • Name
  • Name

Max. 120mV Ripple Industrial Power Supply 47-63Hz Input Frequency

Brand Name: KRONZ
Model Number: PRP100-15A40
MOQ: 1
Price: Negotiable
Packaging Details: Box Packing
Payment Terms: T/T, Western Union,
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE
Document:
Product Brochure PDF
Efficiency (230VAC, %/ Typ.):
89
Ripple (20MHz ):
Max. 120mV
Safety Standards:
UL/ IEC62368-1, IS13252(Par1)&EN62368-1, EN61558-1/ -2-16, BS EN 62368-1
Power-down Hold Time:
30ms (230VAC)
Maximum Capacitive Load (μF):
6400
Output Voltage&Current:
15V/6.5A
Input Current:
3.0A (115VAC) ; 1.6A (230VAC)
Load Regulation:
±1.5% (230VAC)
Supply Ability:
10000 pieces per month
Highlight:

120mV Industrial Power Supply

,

63Hz Ripple Industrial Power Supply

Product Description
Max. 120mV Ripple Industrial Power Supply 47-63Hz Input Frequency
Key Specifications
Attribute Value
Efficiency (230VAC, %/ Typ.) 89
Ripple (20MHz) Max. 120mV
Safety standards UL/ IEC62368-1, IS13252(Par1)&EN62368-1, EN61558-1/ -2-16, BS EN 62368-1
Power-down hold time 30ms (230VAC)
Maximum capacitive load (μF) 6400
Output Voltage & Current 15V/6.5A
Input current 3.0A (115VAC); 1.6A (230VAC)
Load regulation ±1.5% (230VAC)
Product Overview
This high-quality industrial power supply delivers stable 15V/6.5A output for demanding industrial applications. With ±2% voltage accuracy and max 120mV ripple at 20MHz, it ensures clean, reliable power for sensitive equipment.
Industrial Power Supply unit Power Supply side view
Technical Specifications
Model number for ordering PRP100-15A40
Output power 97.5w
Nominal output voltage & current 15V/6.5A
Adjustable output voltage range (ADJ) 13.5~18.0
Efficiency (230VAC, %/Typ.) 89
Maximum capacitive load (μF) 6400
Input Characteristics
AC Input voltage 85~264VAC
DC Input voltage 120~370VDC
Input current 3.0A (115VAC); 1.6A (230VAC)
Input frequency 47~63Hz
Output Characteristics
Output voltage accuracy ±2%
Load regulation ±1.5% (230VAC)
Ripple (20MHz) Max. 120mV
Power-down hold time 30ms (230VAC)
General Features
Operating temperature -40~+70°C
Weight 235g
Safety standards UL/IEC62368-1,IS13252(Par1)&EN62368-1,EN61558-1/-2-16,BS EN 62368-1
Power Supply technical diagram
Industrial Applications
This versatile power supply is ideal for demanding industrial environments:
  • Factory automation systems and industrial machinery
  • PLC controls and industrial automation equipment
  • Telecommunications infrastructure with 30ms hold-up time
  • Test and measurement instruments requiring precise voltage
  • Security systems and surveillance equipment
Power Supply in industrial application Power Supply installation example
Support & Services
Comprehensive technical support including troubleshooting, maintenance services, and product training programs to ensure optimal performance.
Packaging & Shipping
Each unit is securely packaged in protective foam within sturdy cardboard boxes. Shipped via reliable carriers with tracking provided.
Power Supply packaging Contact us for more information
