Home /Products/Industrial Power Supplies/Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply

Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply

1
MOQ
Negotiable
Price
Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply
Features Gallery Product Description Request A Quote
Features
Specifications
Output Voltage&Current: 15V/9.5A
Adjustable Output Voltage Range(ADJ): 13.5-18.0
AC Input Voltage: 85~264VAC
Ripple (20MHz ): Max. 120mV
Power-down Hold Time: 12ms(115VAC);30ms (230VAC)
Efficiency (230VAC, %/ Typ.): 89.5
Weight: 330g
Load Regulation: ±1.0% (230VAC)
Highlight:

Ultra thin Industrial Power Supply

,

9.5A Industrial Power Supply

,

Din rail Industrial Power Supply
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: PRP150-15A40
Document: KRONZ Power Supplies 2025v5....1.pdf
Payment & Shipping Terms
Packaging Details: Box Packing
Delivery Time: 5-8 working days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 10000 pieces per month
Product Description
Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply
Key Specifications
Attribute Value
Output Voltage & Current 15V/9.5A
Adjustable output voltage range (ADJ) 13.5-18.0
AC Input voltage 85~264VAC
Ripple (20MHz) Max. 120mV
Power-down hold time 12ms(115VAC);30ms (230VAC)
Efficiency (230VAC, %/ Typ.) 89.5
Weight 330g
Load regulation ±1.0% (230VAC)
Product Overview

The Industrial Power Supply is a reliable and efficient solution designed to meet the power needs of industrial applications. This Industrial Power Converter operates with an input frequency range of 47~63Hz, making it suitable for various industrial environments.

What are industrial power supplies?

They're ruggedized units converting AC to clean DC power for factories. Key features:

  • Reliability: Operate in -25°C to +70°C & survive 5G vibrations
  • Stability: Keep voltage within ±0.2% during motor startups
  • Safety: Short-circuit protection & IP67 dust/water resistance
  • Smart: Monitor health via Modbus/IO-Link (e.g., predict failures)
Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 0 Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 1
Technical Specifications
Model number for ordering PRP150-15A40
Output power 142.5w
Nominal output voltage & current 15V/9.5A
Adjustable output voltage range (ADJ) 13.5~18.0
Efficiency (230VAC, %/ Typ.) 89.5
Maximum capacitive load (μF) 8000
Input characteristics
AC Input voltage 85~264VAC
DC Input voltage 120~370VDC
Input current 3.0A (115VAC) ; 1.8A (230VAC)
Input frequency 47~63Hz
Output characteristics
Output voltage accuracy ±2%
Load regulation ±1% (230VAC)
Ripple (20MHz) Max. 120mV
Power-down hold time 12ms (115VAC) ; 30ms (230VAC)
Generic features
Operating temperature -40~+70°C
Weight 330g
Safety standards EN62368-1,IS13252(Part1);UL/IEC62368-1,EN/IEC60335-1,IEC61558-1,UL61010-1
Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 2 Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 3
Applications

KRONZ Industrial Power Supply, model PRP150-14A40, is a versatile and reliable high voltage power supply designed for a wide range of industrial applications. With its robust design and precise output characteristics, this DC/DC converter is suitable for various occasions and scenarios where stable power supply is essential.

How do they differ from commercial power supplies?

Three critical gaps:

  • Durability: Industrial units last 5x longer (>500,000 hrs MTBF)
  • Noise Immunity: <50mV ripple noise vs. commercial >200mV
  • Certifications: Meet EN 61000-6-2 (EMC) & UL 61010 (safety)
Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 4 Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 5
Industrial Power Supply 150W Ultra-thin 105mm Width 15V/9.5A DIN-rail Mini Power Supply 6
