Field Wireable Assembly M8 Connectors 5 Pin B Code Straight Male

Brand Name: KRONZ
Model Number: H0805BM-0
MOQ: 50 pieces
Price: Negotiable
Packaging Details: Polybag packing
Payment Terms: T/T, Western Union, MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE
Document:
Product Brochure PDF
Product Name:
M8 Connector
Type:
Contact
Standard:
IEC 61076-2-104
Contact Nut Material:
Brass
Contact Carrier Material:
PA
Housing Material:
PBT
Seal Material:
FPM/FKM
External Cable Diameter:
3.5-5mm
Supply Ability:
100000 pieces per month
Highlight:

Field Wireable Assembly M8 Connectors

,

M8 Connectors 5 Pin

,

Field Wireable Assembly M8 Male Connectors

Product Description
Field Wireable Assembly M8 Connectors 5 Pin B Code Straight Male
Product Specifications
Attribute Value
Product name M8 Connector
Type Contact
Standard IEC 61076-2-104
Contact nut material Brass
Contact carrier material PA
Housing material PBT
Seal material FPM/FKM
External cable diameter 3.5-5mm
Product Description

Field-wireable Assembly Connector M8 Connectors 5 Pin B Code Straight Male

Field Wireable Assembly M8 Connectors 5 Pin B Code Straight Male 0 Field Wireable Assembly M8 Connectors 5 Pin B Code Straight Male 1
Technical Data
Standard IEC 61076-2-104
Contact nut material Brass, nickle-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material PBT/PA, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP67
Configuration Details
Pin assignment Connection method Coding Rated current Voltage Cable outlet External cable diameter Model No.
Field Wireable Assembly M8 Connectors 5 Pin B Code Straight Male 2 Screw connection A 3A 30V Straight 3.5-5mm H0805BM-0
