M12 Connector U12 Industrial Ultrasonic Sensors Blind Zone 0-20mm 4 Pin
  • Name
  • Name

M12 Connector U12 Industrial Ultrasonic Sensors Blind Zone 0-20mm 4 Pin

Brand Name: KRONZ
Model Number: U12-D200UT-R00A
MOQ: 5 pieces
Price: Negotiable
Packaging Details: Polybag packing
Payment Terms: T/T, Western Union, MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE
Document:
Product Brochure PDF
Description:
U12 Ultrasonic Sensors 20-200mm
Detection Range:
20-200mm
Analog Output:
4-20mA
Voltage:
10-30V DC
Connection Type:
4 Pin,M12 Connector
Load Impedance:
I/ ＜ 300 Ohm,U/ ＞ 1k Ohm
Response Time:
22ms
No-load Current:
≤30mA
Supply Ability:
100000 pieces per month
Highlight:

M12 Connector U12 Industrial Ultrasonic Sensors

,

Industrial Ultrasonic Sensors 4 Pin

,

4 Pin M12 Industrial Ultrasonic Sensors

Product Description
M12 Connector U12 Industrial Ultrasonic Sensors Blind Zone 0-20mm 4 Pin
Key Specifications
Attribute Value
Description U12 Ultrasonic Sensors 20-200mm
Detection Range 20-200mm
Analog Output 4-20mA
Voltage 10-30V DC
Connection type 4 pin, M12 connector
Load impedance I/ ＜ 300 Ohm, U/ ＞ 1k Ohm
Response Time 22ms
No-load Current ≤30mA
Product Overview

U12 Ultrasonic Sensor with Blind Zone 0-20mm, Analog Voltage Output, 4 Pin M12 Connector

Main Features
  • M12 installation threaded sleeve with full length of only 57mm
  • Small blind zone and sound cone for precise close-range detection
Basic Features
  • 1 analog current output 4-20mA
  • Distance learning function via white lines
  • Built-in temperature compensation
  • Standard operating voltage DC 10-30V
Technical Specifications
Model U12-D200UT-R00A
Detection range 20-200mm
Blind zone 0-20mm
Resolution 0.1mm
Repeatability ±0.15%F.S.
Accuracy ±1% (with built-in temperature drift compensation)
Response time 22ms
Initialization time ＜ 500ms
Supply voltage 10-30V DC with reverse-polarity protection
LED Indicators Red: no object detected (Lights up), Green: object detected (Lights up)
Overcurrent protection 200mA (LEDs flash simultaneously)
Load impedance I/ ＜ 300 Ohm, U/ ＞ 1k Ohm
No-load current ≤30mA
Input type Teach-in and synchronization
Material Copper nickel-plated, plastic fittings, glass epoxy resin
Enclosure rating IP67
Connection type 4pin, M12 connector
Ambient temperature -25℃ ~ +70℃ (248~343K)
Storage temperature -40℃ ~ +85℃ (233~358K)
Weight 20g
Output type I: 1 analog current output 0-10V
Dimensional Drawing
M12 Connector U12 Industrial Ultrasonic Sensors Blind Zone 0-20mm 4 Pin 0
