M30 Ultrasonic Sensor Red LED Lights Up Green LED Flashing 60-1000mm Sensing Range

Brand Name:	KRONZ
Model Number:	U18-D1000UIT-R00A
MOQ:	1
Price:	Negotiable
Packaging Details:	Polybag packing
Payment Terms:	T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

Document:

Product Brochure PDF

Output Type N2I:

1 Analog Voltage Output 0-10V +1 Analog Current Output 4-20mA, Up/down

Overcurrent Protection:

200mA,Red LED And Green LED Flashing At The Same Time

Initialization Time:

＜ 500ms

Repeatability:

±0.15%F.S.

Red LED:

No Object Detected:Lights Up, Teaching-in When No Object Detected:Flashes

Accuracy:

±1%(built-in Temperature Drift Compensation)

Enclosure Rating:

IP67

Load Impedance:

I/<300 Ohm, U/> 1K Ohm

Supply Ability:

100000 pieces per month

Highlight:

1000mm Ultrasonic Sensor

M30 Ultrasonic Sensor

Green LED Flashing Ultrasonic Sensor

Product Description

M30 Ultrasonic Sensor Red LED Lights Up Green LED Flashing 60-1000mm Sensing Range

Product Attributes

Attribute	Value
Output Type N2I	1 Analog Voltage Output 0-10V +1 Analog Current Output 4-20mA, Up/down
Overcurrent protection	200mA, Red LED And Green LED Flashing At The Same Time
Initialization time	＜ 500ms
Repeatability	±0.15%F.S.
Red LED	No Object Detected: Lights Up, Teaching-in When No Object Detected: Flashes
Accuracy	±1%(built-in Temperature Drift Compensation)
Enclosure Rating	IP67
Load Impedance	I/<300 Ohm, U/> 1K Ohm

Product Description

The Industrial Ultrasonic Sensor is a high-precision device with LED display, designed for accurate distance measurement in industrial environments. With a resolution of 0.17mm and sensing range of 60-1000mm, it delivers reliable performance in demanding applications.

Key Features

Dual output: 1 Analog Voltage Output (0-10V) + 1 Analog Current Output (4-20mA)
Robust construction: Copper Nikel-plated, plastic fittings, and glass epoxy resin
Visual indicators: Red and Green LED status lights
Built-in overcurrent protection (200mA)
Wide operating temperature range: -25℃ to +70℃
IP67 enclosure rating for harsh environments

Technical Specifications

Accuracy	±1% (built-in Temperature Drift Compensation)
Connection Type	5pin, M12 Connector
Output Type UI	1 Analog Voltage Output 0-10V +1 Analog Current Output 4-20mA, Up/down
Enclosure Rating	IP67
Supply voltage	10-30V DC, reverse-polarity Protection
Repeatability	±0.15%F.S.
Weight	38g

Applications

The KRONZ Industrial Ultrasonic Sensor is ideal for various industrial applications including:

Object detection in manufacturing processes
Liquid level monitoring in tanks
Precision spacing in automated systems
Industrial automation and control systems
