M12 Connector 8 Pin Straight with 2 Meter PVC Cable Female Circular Connectors

50 pieces
MOQ
Negotiable
Price
M12 Connector 8 Pin Straight with 2 Meter PVC Cable Female Circular Connectors
Features Gallery Product Description Request A Quote
Features
Specifications
Description: M12 Connector With Pre-assembled Cable
Wire Gauge: 8×0.25 (8×24AWG) PVC, Black
Contact Carrier Material: PA, Black
Standard: IEC 61076-2-101
Seal Material: FPM/FKM
Pollution Degree: 3
Ambient Temperature: -25~+85℃
Degree Of Protection: IP67
Highlight:

TPU Housing M12 Connector

,

Straight M12 Connector 8 Pin

,

8 Pin M12 Female Connector
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: M1208F-2/P00R
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Product Description
M12 Connector 8 Pin Straight with 2 Meter PVC Cable Female Circular Connectors
Product Overview

M12 connector with pre-assembled cable designed for industrial applications requiring reliable connectivity in demanding environments.

Key Features
  • 8-pin straight configuration with 2 meter PVC cable
  • Female circular connectors with IP67 protection
  • Designed for food and beverage industry washdown environments
  • Stainless steel construction withstands cleaning agents
M12 Connector 8 Pin Straight with 2 Meter PVC Cable Female Circular Connectors 0
Technical Specifications
Attribute Value
Standard IEC 61076-2-101
Contact nut material Brass, nickel-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material TPU, black
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP67
Pin Configuration & Cable Details
Pin assignment Wire color Coding Rated current Voltage Wire gauge Cable outlet Length Model No.
M12 Connector 8 Pin Straight with 2 Meter PVC Cable Female Circular Connectors 1 1=WH 2=BU
3=GN
4=YE 5=GY
6=PK 7=BU
8=RD		 A 2A 30V 8×0.25 (8×24AWG) PVC, black Straight 2M M1208F-2/P00R
5M M1208F-5/P00R
10M M1208F-10/P00R
