Male M12 Connectors 12 Pin IEC 61076-2-101 Unshield Pre Assembled Cable Straight

Brand Name: KRONZ
Model Number: M1212M-2/P00R
MOQ: 50 pieces
Price: Negotiable
Packaging Details: Polybag packing
Payment Terms: T/T, Western Union, MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE
Document:
Product Brochure PDF
Description:
M12 12Pin Connectors
Pin:
12
Wire Color:
1=BN 2=BU 3=WH 4=GN 5=PK 6=YE 7=BK 8=GY 9=RD 10=VT 11=GY/PK 12=RD/BU
Contact Nut Material:
Brass, Nickle-plated
Contact Resistance:
≤5mΩ
Wire Gauge:
8×0.25 (8×24AWG) PVC, Black
Pollution Degree:
3
Mating Cycles:
>100
Supply Ability:
100000 pieces per month
Highlight:

Male M12 Connectors 12 Pin

,

Unshield Cable M12 Connectors 12 Pin

,

Pre Assembled Cable Straight M12 Connectors

Product Description
Male M12 Connectors 12 Pin IEC 61076-2-101 Unshield Pre Assembled Cable Straight
Product Overview

M12 connector is a circular connector with a 12-millimeter diameter thread, commonly used in industrial automation and control systems. It is designed to provide reliable connections for sensors, actuators, and other field devices in harsh environments.

Male M12 Connectors 12 Pin IEC 61076-2-101 Unshield Pre Assembled Cable Straight 0
Key Specifications
Standard: IEC 61076-2-101
Contact nut material: Brass, nickle-plated
Contact surface: Brass, gold-plated
Contact carrier: PA, black
Housing material: TPU, black
Seal material: FPM/FKM
Insulation resistance: ≥100MΩ
Contact resistance: ≤5mΩ
Pollution degree: 3
Temperature range: -25~+85℃
Mating cycles: >100
Protection rating: IP67
Pin Configuration
Male M12 Connectors 12 Pin IEC 61076-2-101 Unshield Pre Assembled Cable Straight 1
Pin Wire Color Coding Rated Current Voltage Wire Gauge
1 BN (Brown) A 1.5A 30V 12×0.14 (12×26AWG)
PVC, black
2BU (Blue)
3WH (White)
4GN (Green)
5PK (Pink)
6YE (Yellow)
7BK (Black)
8GY (Gray)
9RD (Red)
10VT (Violet)
11GY/PK (Gray/Pink)
12RD/BU (Red/Blue)
Available Models
Cable Length Model Number
2M M1212M-2/P00R
5M M1212M-5/P00R
10M M1212M-10/P00R
