Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67
  • Name
  • Name

Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67

Brand Name: KRONZ
Model Number: F1208M-0.5R/M16
MOQ: 50 pieces
Price: Negotiable
Packaging Details: Polybag packing
Payment Terms: T/T, Western Union,
Detail Information
Product Description
Ratings & Reviews
Detail Information
Place of Origin:
Guangdong, China
Certification:
CE
Document:
Product Brochure PDF
Type:
M12 Connector
Decription:
Male Flange Connectors
Voltage:
30V
Contacts:
0.5m Pre-wired
Standard:
IEC 61076-2-101
Contact Nut Material:
Brass, Nickle-plated
Contact Surface Material:
Brass, Gold-plated
Contact Carrier Material:
PA, Black
Supply Ability:
100000 pieces per month
Highlight:

Panel Mount M12 Connector

,

PCB Version M12 Connector Male

,

Rear Mounting M12 Connector Male

Product Description
Panel Mount M12 Connector Male Rear Mounting PCB Version M16 X 1.5 IP67
Product Specifications
Attribute Value
Type M12 connector
Description Male flange connectors
Voltage 30V
Contacts 0.5m Pre-wired
Standard IEC 61076-2-101
Contact nut material Brass, nickel-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Product Overview

The M12 panel mounted connector male head provides reliable electronic connections for industrial applications. Featuring a post-installation method for convenient device integration and PCB version design for stable circuit connections.

M12 Panel Mount Connector Male Rear Mounting PCB Version
Technical Specifications
Standard IEC 61076-2-101
Contact nut material Brass, nickel-plated
Contact surface material Brass, gold-plated
Contact carrier material PA, black
Housing material Brass, nickel-plated
Seal material FPM/FKM
Insulation resistance ≥100MΩ
Contact resistance ≤5mΩ
Pollution degree 3
Ambient temperature -25~+85℃
Mating cycles >100
Degree of protection IP67
Configuration Details
Pin assignment Mounting type Coding Rated current Voltage Cable outlet Contacts termination Part No.
Pin assignment diagram Rear mounting A 2A 30V Straight 0.5m Pre-wired F1208M-0.5R/M16
Key Features
  • Precise M16 x 1.5 specification for strong compatibility
  • Excellent durability and anti-interference performance
  • Stable connections in complex working environments
  • Ideal for industrial automation and communication equipment
  • Efficient and reliable connection solution
Ratings & Review

Overall Rating

5.0
Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings
5 stars
100%
4 stars
0%
3 stars
0%
2 stars
0%
1 stars
0%

All Reviews

M
Miguel
United States Jul 1.2026
Helpful (15)
Good quality M12 connector & cable/wire. Worked as expected.
G
Gvrita
United States May 28.2026
Helpful (11)
Good quality connector and cable
F
Frank
United States Jan 26.2026
Helpful (30)
I used this to connect to a small solar panel and then connected that to my yard robots GPS locator. It needs power and a good line of sight to the sky. I didn't feel like running a cord across the yard.
Tags:

Cable Assembly Connector

M12 Circular Connectors

M12 Panel Mount Connector
