7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections

5
MOQ
Negotiable
Price
7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections
Features Gallery Product Description Request A Quote
Features
Specifications
Cable Outlet: Straight
Seal Material: FPM/FKM
Description: 7/8
Usage: For Power Applications
Insulation Resistance: ≥100MΩ
Contact Nut Material: Brass, Nickle-plated
Mating Cycles: >100
Shielded: No
Highlight:

PA Contact Carrier 7/8 Connector

,

Durable Connections 7/8 Connector

,

Brass Connectors 7/8 Connector
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: F7804F-05R/13.5
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Product Description
7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections
Product Specifications
Attribute Value
Cable Outlet Straight
Seal Material FPM/FKM
Description 7/8
Usage For Power Applications
Insulation resistance ≥100MΩ
Contact Nut Material Brass, Nickle-plated
Mating cycles >100
Shielded No
Product Overview

The 7/8" Connector is a high-quality industrial-grade product designed for reliable and durable power connections. Featuring a sturdy metal shell construction with FPM/FKM sealing material, it provides excellent protection against moisture and dust in demanding environments.

Key Features
  • Contact Carrier Material: PA, Black
  • Maximum Pressure: 150 PSI
  • Insulation resistance: ≥100MΩ
  • Degree Of Protection: IP67
  • Voltage Rating: 300V
  • Rated Current: 9A
  • Male Connection Type for secure integration
7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 0 7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 1 7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 2
Technical Parameters
Shielded No
Application Industrial Automation
Cable Outlet Straight
Voltage 300V
Maximum Pressure 150 PSI
Thread 7/8"-16UN
Contacts Termination Solder Cup
Ambient temperature -25~+85℃
Industrial Applications

This versatile connector is ideal for:

  • Industrial automation systems and machinery
  • Solar energy applications including panels and inverters
  • Industrial Ethernet connections
  • Sensor applications requiring secure connections
Support & Services

Our product support includes comprehensive technical assistance for installation, troubleshooting, and maintenance. We provide training resources to optimize connector performance and longevity.

7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 3 7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 4 7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 5 7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 6 7/8 Connector PA Contact Carrier Material Brass Connectors For Durable Connections 7
Tag:

7/8" Circular Connector

Wireable Field Assembly Connector

Waterproof 7/8" Connector
