M12 Female Connector Screw Connection ABS Contact Carrier Material for Industrial Needs

Brand Name:	KRONZ
Model Number:	H1205FA-9/L
MOQ:	5
Price:	Negotiable
Packaging Details:	Polybag packing
Payment Terms:	T/T, Western Union, MoneyGram

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Certification:

Document:

Product Brochure PDF

Contact Carrier Material:

ABS, PA, Black

Contact Surface Material:

Brass, Gold-plated

Rated Current:

Insulation Resistance:

≥100MΩ

Pollution Degree:

Contact Resistance:

≤5mΩ

Cable Outlet Diameter:

4-8mm

Contact Nut Material:

Brass, Alloy

Supply Ability:

100000 pieces per month

Highlight:

Screw Connection M12 Female Connector

Industrial M12 Female Connector

4A Rated Current M12 Connector

Product Description

M12 Female Connector Screw Connection ABS Contact Carrier Material for Industrial Needs

Product Specifications

Attribute	Value
Contact carrier material	ABS, PA, Black
Contact surface material	Brass, Gold-plated
Rated current	4A
Insulation resistance	≥100MΩ
Pollution degree	3
Contact resistance	≤5mΩ
Cable Outlet Diameter	4-8mm
Contact nut material	Brass, Alloy

Product Description

The M12 Connector is an ideal solution for industrial connectivity needs, featuring a pre-assembled cable with angle outlet for flexible installation. Designed with Coding A for secure mating connections, this robust connector prevents mismating and ensures reliable performance in demanding applications.

Key Features

Housing material: TPU, Black
Ambient temperature range: -25 to +85℃
Screw connection type
Insulation resistance: ≥100MΩ
Gold-plated brass contact surfaces
Durable design with >100 mating cycles
Available in 4, 5, or 8 pin configurations

Technical Parameters

Clamp matrix material	ABS, PBT/PA, Black
Seal material	NBR
Mating cycles	>100
Voltage	60V
Rated current	4A
Coding	A
Connect	Screw Connection
Cable outlet	Angle
Pin	5
Pollution degree	3

Applications

KRONZ M12 Connectors are versatile solutions for industrial automation, machinery, and sensor applications. Certified to IEC 61076-2-101 standard, these connectors offer reliable performance in diverse environmental conditions (-25 to +85℃) with excellent electrical properties (≥100MΩ insulation resistance, ≤5mΩ contact resistance).

Support and Services

Our technical support team provides comprehensive assistance for installation, configuration, and troubleshooting to ensure optimal performance of your M12 Connectors.

Packing and Shipping

Each M12 Connector is packed with warranty information. Standard shipping delivers within 5-7 business days.
