M12 Circular Connector for Heavy-Duty Applications Rated Current 2A Waterproof Angle 5 Pin

Brand Name:	KRONZ
Model Number:	H1208FA-9/L
MOQ:	5
Price:	Negotiable
Packaging Details:	Polybag packing
Payment Terms:	T/T, Western Union,

Detail Information

Product Description

Ratings & Reviews

Detail Information

Place of Origin:

Guangdong, China

Certification:

Document:

Product Brochure PDF

Contact Carrier Material:

ABS, PA, Black

Contact Surface Material:

Brass, Gold-plated

Voltage:

30V

Mating Cycles:

>100

Insulation Resistance:

≥100MΩ

Rated Current:

Gender:

Female

Clamp Matrix Material:

ABS, PBT/PA, Black

Supply Ability:

100000 pieces per month

Highlight:

Heavy Duty M12 Circular Connector

5 Pin M12 Circular Connector

Waterproof M12 Circular Connector

Product Description

M12 Circular Connector for Heavy-Duty Applications Rated Current 2A Waterproof Angle 5 Pin

Product Specifications

Attribute	Value
Contact carrier material	ABS, PA, Black
Contact surface material	Brass, Gold-plated
Voltage	30V
Mating cycles	>100
Insulation resistance	≥100MΩ
Rated current	2A
Gender	Female
Clamp matrix material	ABS, PBT/PA, Black

Product Overview

The M12 Connector with Pre-molded Cable is a durable connectivity solution featuring a TPU housing in black. Engineered for industrial environments, it offers reliable performance with over 100 mating cycles and excellent corrosion resistance through its gold-plated brass contacts.

Key Features

Robust TPU housing material in black
Gold-plated brass contacts for superior conductivity
Compliant with IEC 61076-2-101 standard
Screw connection mechanism for secure installation
IP67 protection rating for harsh environments
Angle cable outlet design
2A rated current capacity

Technical Parameters

Gender	Female
Insulation resistance	≥100MΩ
Contact nut material	Brass, Alloy
Standard	IEC 61076-2-101
Degree of protection	IP67
Voltage	30V
Cable Outlet Diameter	4-8mm

Applications

This M12 connector is ideal for industrial automation, machinery, and sensor applications requiring reliable waterproof connections. Its IP67 rating makes it suitable for environments with dust, moisture, and vibration.

Support & Services

Expert technical support and troubleshooting
Installation and maintenance guidance
Software/firmware updates
Comprehensive training resources
Warranty coverage and repair services

Packaging & Shipping

Each M12 Connector is securely packaged in protective polybags. Standard shipping delivers within 3-5 business days.

Ratings & Review

Overall Rating

5.0

Based on 50 reviews for this supplier

Rating Snapshot

The following is the distribution of all ratings

5 stars

100%

4 stars

3 stars

2 stars

1 stars

All Reviews

United States Jun 23.2026

Helpful (68)

This is a high quality, industrial style connector. It's great for robotics or industrial controls where you need a water tight connection you can easily disconnect. I'm using it to connect a remote GPS serial port signal, and it's working great. It's a good value, and it's just as good quality as you will get from the big industrial electronics stores.

Gvrita

United States May 28.2026

Helpful (11)

Good quality connector and cable

Cameron MacDonald

United States May 1.2026

Helpful (63)

Good quality connector and cable. Worked great for a control project I was doing and arrived faster than I could get it anywhere else. Real copper wire and brass pins. Solid housing and good strain relief. Very pleased.
