Home /Products/M12 Connectors/M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors

M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors

5
MOQ
Negotiable
Price
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors
Features Gallery Product Description Request A Quote
Features
Specifications
Rated Current: 4A
Cable Outlet: Angle
Contact Resistance: ≤5mΩ
Degree Of Protection: IP67
Clamp Matrix Material: ABS, PBT/PA, Black
Mating Cycles: >100
Connect: Screw Connection
Standard: IEC 61076-2-101
Highlight:

Aviation M12 Plug Connector

,

5 Pin M12 Plug Connector

,

Screw Connect M12 Plug Connector
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: H1205MA-9/L
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 100000 pieces per month
Product Description
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors
Product Attributes
Attribute Value
Rated current 4A
Cable outlet Angle
Contact resistance ≤5mΩ
Degree of protection IP67
Clamp matrix material ABS, PBT/PA, Black
Mating cycles >100
Connect Screw Connection
Standard IEC 61076-2-101
Product Description
The M12 5-pin Connector is a versatile and reliable solution for various industrial applications. Featuring an angle cable outlet, this A-code connector ensures easy installation and secure connection in tight spaces. With a contact resistance of ≤5mΩ, this M12 Connector guarantees efficient and stable signal transmission, enhancing overall system performance.
Designed to withstand harsh environments, this M12 Connector is rated for pollution degree 3, making it suitable for industrial settings where dust and contaminants may be present. The connector's robust construction and NBR seal material provide excellent protection against environmental factors, ensuring long-term durability and reliable operation.
Operating within a wide temperature range of -25 to +85℃, this M12 Connector handles extreme temperature variations, making it ideal for both indoor and outdoor applications. The pre-molded cable design simplifies installation and reduces wiring errors, ensuring a secure and consistent connection.
Key Features
  • M12 Connector with A-coding
  • Degree of protection: IP67
  • Contact nut material: Brass, Alloy
  • Contact surface material: Brass, Gold-plated
  • Rated current: 4A
  • Screw connection type
  • Mating cycles: >100
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors 0
Technical Specifications
Parameter Value
Connector Type M12 A-code
Configuration Angled
Ambient temperature -25~+85℃
Connection Type Screw Connection
Degree of protection IP67
Voltage 60V
Insulation resistance ≥100MΩ
Applications
KRONZ M12 connectors are versatile solutions for industrial applications requiring secure connections. Ideal for machinery, automation systems, and sensor applications, these connectors offer:
  • CE certified quality
  • Minimum order quantity: 5 pieces
  • Supply capacity: 100,000 pieces/month
  • Delivery within 5-8 working days
  • Multiple payment options available
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors 1
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors 2
Support and Services
Our comprehensive technical support includes:
  • Installation guidance
  • Troubleshooting assistance
  • Maintenance recommendations
  • Training programs
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors 3
Packaging and Shipping
Packaging: Each M12 Connector is individually wrapped in bubble wrap and packed in durable cardboard boxes for maximum protection during transit.
Shipping: Orders ship within 1-2 business days with tracking provided. Multiple shipping options available to meet your requirements.
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors 4
M12 Plug Connector A-code 5 Pin Aviation Screw Connect Male Circular Connectors 5
