Attribute	Value
Product name	M12 Connectors with molded cable
Seal material	FPM/FKM
IP rate	IP67
Standard	IEC 61076-2-101
Ambient temperature	-25~+85℃
Contact nut material	Brass, nickel-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black

Product Description

M12 Connectors with Molded Cable Female Angled 12 Pin IP67 black PVC

Cable length: 2/5/10m, other cable lengths are available on request! Freely selectable cable material (P00R: black PVC, P01R: black PUR). For more details, please consult our customer service.

Technical Data

Standard	IEC 61076-2-101
Contact nut material	Brass, nickel-plated
Contact surface material	Brass, gold-plated
Contact carrier material	PA, black
Housing material	TPU, black
Seal material	FPM/FKM
Insulation resistance	≥100MΩ
Contact resistance	≤5mΩ
Pollution degree	3
Ambient temperature	-25~+85℃
Mating cycles	>100
Degree of protection	IP67

Pin Configuration

Connection method	Coding	Rated current	Voltage	Wire gauge	Cable outlet	Length	Model No.
1=BN 2=BU 3=WH 4=GN 5=PK 6=YE 7=BK 8=GY 9=RD 10=VT 11=GY/PK 12=RD/BU	A	1.5A	30V	12×0.14 (12×26AWG) PVC, black	Angled	2M	M1212FA-2/P00R
						5M	M1212FA-5/P00R
						10M	M1212FA-10/P00R
