Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source

1
MOQ
Negotiable
Price
Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source
Features Gallery Product Description Request A Quote
Features
Specifications
Housing Material: Housing: PBT, Lens: PMMA
Sampling Period: 500/ 1000/ 1500/ 2000μs
Storage Humidity: 35~95%RH(no Condensation Or Icing)
Storage Temperature: -20~60°C
Ambient Illuminance: Sunlight: ≤10000lux, Lamp:≤3000lux
Spot Size (max.) Center Range: 1.75x3.5mm
Connection Type: Cable
Wavelength: 655nm
Highlight:

Industrial Grade Photoelectric Sensors

,

Red Laser Diode Photoelectric Sensors
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: KRONZ
Certification: CE
Model Number: KD50-250N
Document: Product Brochure PDF
Payment & Shipping Terms
Packaging Details: Polybag packing
Delivery Time: 5-8 working days
Payment Terms: T/T,Western Union,MoneyGram
Supply Ability: 10000 pieces per month
Product Description
Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source
Product Specifications
Attribute Value
Housing Material Housing: PBT, Lens: PMMA
Sampling Period 500/1000/1500/2000μs
Storage Humidity 35~95%RH (no Condensation Or Icing)
Storage Temperature -20~60°C
Ambient Illuminance Sunlight: ≤10000lux, Lamp:≤3000lux
Spot Size (max.) Center Range 1.75x3.5mm
Connection Type Cable
Wavelength 655nm
Product Overview

Our industrial-grade photoelectric sensors deliver high-precision detection with micron-level accuracy, fast response times, and stable readings across various surfaces. The compact, robust design is engineered for demanding industrial environments.

Key Advantages
  • High precision (micron-level accuracy)
  • Fast response time
  • Stable readings on a variety of surfaces
  • Compact and robust design for industrial environments
Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 0 Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 1
Technical Specifications
Cable Type 2CH KD50-250N
Output Signal Switching output: NPN (-N)
Detection Range 250±150mm
Full Scale(F.S.) 300mm
Light Source Red Laser diode (wavelength 655nm)
IEC/JIS Rating(FDA Rating) Class 2(Class Ⅱ)
Sampling Period 500(250mm:750)/1000/1500/2000μs
Spot Size (max.) Near Range 1.5x2.5mm
Spot Size (max.) Center Range 1.75x3.5mm
Spot Size (max.) Far Range 2.0x4.5mm
Repeatability High-speed Mode 100μm
Repeatability Other Mode 75μm
Shock Resistance 50G(500m/s²)
Housing Material Housing: PBT Lens: PMMA
Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 2 Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 3 Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 4
Industrial Applications

These high-performance photoelectric sensors are ideal for industrial automation applications including:

  • Precision object detection
  • Automated counting systems
  • Positioning and alignment tasks
  • Quality control inspection
  • Process monitoring
Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 5 Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 6 Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 7 Industrial Grade Photoelectric Sensors with ±0.1%F.S. Linearity Accuracy and Red Laser Diode Light Source 8
Tag:

IP67 Photoelectric Sensors

Photoelectric Sensors 24V DC

Industrial Photoelectric Sensor
